Sonance VX66 LCR In Wall Speakers Factory Sealed (each)

Product Overview
The Sonance VX66 LCR is a high-performance rectangular LCR architectural speaker designed for front-stage home theater sound (Left, Center, Right) with a clean, low-profile finish. It uses Sonance’s Micro-Trim aesthetic with a Brilliant White (Satin) grille (brighter, more consistent white with a smaller bezel to reduce shadow lines), and it’s built to deliver crisp dialogue, strong vocal separation, and balanced coverage for TV and movie applications. Installation is streamlined with Sonance’s two-piece Flex Frame mounting system, and the design incorporates constant-directivity crossover engineering plus advanced driver motor topology to keep distortion extremely low while maintaining consistent dispersion across frequencies.

Specs

• Brand: Sonance

• Product Category: Visual Experience

• Model: VX66 LCR

• Speaker Type: LCR Speaker (1 Each)

• Speaker Aesthetic: Micro-Trim (Brilliant White, RAL-standardized)

• Optional Grille: Trimless grille option available (not included unless specified)

• Speaker Shape: Rectangle

• Speaker Size: 6" class

• Color / Finish: Brilliant White (Satin)

• Power Handling: 5W minimum; 140W maximum

• Frequency Response (+/– 3dB): 43Hz – 20kHz

• Sensitivity: 90dB (2.83V/1m)

• Impedance: 8 ohms nominal; 6 ohms minimum

• Dispersion / Voicing: Sinusoidal Textured Waveguide + CDX Constant Directivity Crossovers

• Cutout Dimensions (W x H): 6.94" x 14.57"

• Mounting Depth (Speaker Only): 3.5"

• Mounting Depth (With Retrofit Enclosure): 3.84"

• Grille Dimensions (Micro Trim, W x H): 8.23" x 15.87"

• Grille Dimensions (Trimless, W x H): 7.88" x 15.52"

• Operating Temperature Range: -4°F to 140°F

• Tweeter: 1.0" (25mm) ceramic dome, Ferrofluid-cooled, acoustic back chamber

• Woofers: Two 6.5" (165mm) Kevlar / Nomex cones, rubber surrounds

• Tweeter Pivot: Does not pivot

• Specialty Application: LCR (Front channel staging)

• Warranty: Limited Lifetime

• Shipping Weight: 11.8 lbs

What’s Included

• Sonance VX66 LCR Rectangle Speaker (1 Each)

• Brilliant White Micro Trim Grille

• Two-piece Flex Frame mounting system / mounting hardware (as included by Sonance)

Perfect for minimalist audio setups, this bundle combines discreet in-ceiling sound with smart multi-zone control—everything you need for an integrated home or office sound system.

Have a question about installation or compatibility? We're happy to help.
